PRODUCT
película de vidrio esmerilado eléctrico
Brand: HOMEWELL
Parameter: Input: 110VAC 60HZ or 220VAC 50HZ(only one choice)
Output: 60VAC MAX.30W (other voltages can be customized)
Output frequency = input frequency
Size: 120*99*65mm
Net Weight(with package): 1.1KG
Safe Application Scope: Single side≤5 Square meters
Two sides≤4 Square meters
|
Photoelectric Performance |
Classic laminated smart film |
|
|
Items ON/OFF |
Test Methods/Standards |
|
|
Operating voltage ON 60V |
Multimeter/ Voltage Regulator,WGW |
|
|
Power consumption ON ≤ 5W/m² |
Multi-parameter electric measuring instrument |
|
|
Viewing angle ON ≥ 160° |
Visual Inspection |
|
|
Uv blocking rate OFF ≥ 99% |
Optical transmittance tester |
|
|
Infrared blocking rate OFF ≥ 60% |
||
|
Response time |
OFF→ON ≤ 30ms |
Liquid crystal parameter |
|
Operating temperature -- -30°C ~ 85°C |
constant temperature and humidity testing machine |
|
|
Lifetime -- 10 -15 years |
GB18910.5-2008 |
|
|
Switching times -- ≥2 million times |
Self-made on/off tester |
|
|
La película inteligente funciona con corriente alterna, es incolora y transparente cuando se le agrega corriente, y se vuelve empañada y translúcida cuando se le quita la corriente, y su rendimiento fotoeléctrico se muestra en la tabla anterior. |
||
