The most common technologies used in smart glass are:
Electrochromic Technology: This type of smart glass contains a thin layer of materials that change their optical properties when an electric current is applied. When a voltage is applied, the glass darkens or becomes opaque, blocking the passage of light. Conversely, when the voltage is removed, the glass returns to a transparent state.
Polymer Dispersed Liquid Crystal (PDLC) Technology: PDLC-based smart glass consists of a layer of liquid crystals suspended in a polymer matrix. When an electric current is applied, the liquid crystals align and allow light to pass through, making the glass transparent. When the current is switched off, the liquid crystals scatter and block the light, making the glass opaque.
Suspended Particle Device (SPD) Technology: SPD smart glass contains tiny particles suspended in a liquid or film layer. When an electrical charge is applied, the particles align to allow light to pass through, making the glass transparent. By adjusting the voltage, the particles can be rearranged to block light, making the glass opaque.
|
Product Parameters
|
High temperature PDLC film with hard coating
|
|
Haze（ON）
|
3.5%±1
|
|
Haze（OFF）
|
95.6%±1
|
|
Total light transmittance（ON）
|
84%-85%
|
|
Total light transmittance（OFF）
|
60%-71%
|
|
UV block
|
≥99%
|
|
IR block(OFF)
|
≥60%
|
|
Power consumption
|
≤5W/m²
|
|
Voltage
|
AC60V
|
|
Operating temperature
|
-30℃~105℃
|
Product Function
1) Privacy Protection :
The biggest function of Our pdlc film is privacy protection,which can control the glass between transparent and opaque.It can protect your privacy by our smart film
2) Projection Screem:
Our Pdlc film can be used as a good projection screen, in appropriate light environment, if choose high lumen projector, the image of projection effect is very clear(suggest use rear projection mode).
3) Safety Protection
Our pdlc film thickness is about 0.36mm. When installed on your glass window,It can adhensive your window closely, When the window are broken, The film can avoid the window glass flying around and hurt others,
4) Environmental Protection:
Our PDLC film attached on the surface of glass,Which can resist heat over 98% UV and over 95% infrared ray. In order to reduce thermal radiation, it requires shielding partial infrared ray. While if shielding UV can protect indoor furnishings not fade, aging and so on, and protect people against the disease by ultraviolet radiation.
The benefits of using smart film:
- Energy efficiency: Smart film can be used to create energy-efficient windows by reducing the amount of heat that enters a building, thereby reducing energy costs.
- Aesthetics: Smart film can be used to create decorative displays and dynamic projections, enhancing the visual appeal of any space.
- Easy installation: Smart film is easy to install and can be applied to existing glass surfaces, making it a cost-effective option for renovation and upgrading projects.
- Low maintenance: Smart film requires minimal maintenance and can last for many years, making it a durable and long-lasting investment.
- Versatility: Smart film can be used in various industries and applications, including architecture, automotive, healthcare, and retail.
- Privacy control: Smart film allows users to control their privacy by switching between opaque and transparent modes with the touch of a button or a remote control.
